Rapid heating up and cooling down: maximum heating rate of 8.0℃/s; maximum cooling rate of 6.2℃/s.
High-brightness, maintenance-free LED lightsource with 4 (Gentier 48E)/2 (Gentier 48R) fluorescence detection channels, allowing fluorescence scanning of all wells completed in just 2s.
With a 7-inch full-color touchscreen, the device can operate independently from the computer and store over 1,000 experimental data.
Immediate analysis of experimental data on the instrument, without the need for a computer; direct printing function by connecting to a thermal printer.
Automatic recovery of the experiment when the power is on again after cutting off, without waiting for the power-on of the computer or software control.
Small in size, light in weight, easy to move; and no calibration needed after moving.
|
Model |
STN-48E |
|
Through Out |
48 |
|
Fluorescence Channels |
4 |
|
Compatible Fluorophores |
Channel 1: FAM, SYBR Green I, etc. Channel 2: VIC, HEX, TET, JOE, etc. Channel 3: ROX, Texas Red, etc. Channel 4: Cy5, etc. |
|
Light Source |
High-brightness, long-life and maintenance-free LED light source |
|
Detector |
Photodiodes |
|
Fluorescence Scanning Time |
48-well 4-color detection completed within 2s |
|
Heating Rate |
Maximum Heating Ramp rate ≥8.0°C/s; Average Heating Ramp rate ≥6.2°C/s |
|
Cooling Rate |
Maximum Cooling Ramp rate ≥6.2°C/s; Average Heating Ramp rate ≥4.5°C/s |
|
Temperature Accuracy |
≤0.1°C |
|
Special Temperature Setting function |
Support Thermal gradients PCR, Long PCR, Touch Down PCR |
|
Suitable Consumables |
0.2mL clear non-skirt 48-well plates, 8 tube strips single tubes, etc. |
|
Sample Testing Linearity and Repeatability |
Linear Correlation: /r/ ≥0.999 Repeatability: cycle threshold (Ct) value CV ≤0.5% |
|
Software Analysis |
Qualitative Analysis, absolute quantitative analysis, relative quantitative analysis, end point fluorescence analysis, melting curve analysis, and genotyping analysis, etc |
|
Control Method |
Stand-alone Operation: 7 inch touchscreen control; Cloud-enabled: PC software control via direct connection or LAN (local area network) Up to 10 devices controlled by one PC |
|
Power Failure Protection |
Automatic Recovery of the experiment and other functions when the power is on again after cutting off, without waiting for the power-on of the computer or software control |
|
Data Storage and Transmission |
A single machine can store more the 1,000 experimental data files, which can be imported and exported via USB disks |
|
Stand-Alone Analysis Results |
No need for an extra computer: experiment data analysis enabled within the instrument; Direct Printing function (optional) to output the sample amplification curve and CT value, simply by connecting to the compatible thermal printer |
|
Reporting Function |
Build-in experiment report templates for a variety of industries; Fully open universal reporting of which the contents and formats can be customized |
|
Operating System for PC |
Windows XP Pro or higher |
|
Power Supply and Power Consumption |
AC 100-240V, 50-60Hz, 600VA |
|
Weight |
11kg (net) |
|
Instrument Dimension |
260*400x260mm (WxLxH) |
