Eyepiece |
Plan eyepiece 10×/18mm |
|
Objective |
Long work distance plan objective: 10×/0.25, WD7.3mm; 50×/0.70, WD 0.5mm |
|
Total Magnification |
100×, 500× |
|
Mechanical tube length |
160mm |
|
Focusing range |
20mm |
|
Illumination |
Adjustable LED light(chargeable) |
|
Dimension |
23cm*11cm*7cm |
|
Weight |
0.75kg |
|
Optional Parts |
WF16×, WF20×, WF10×/18 eyepiece with crossing line |
|
Long work distance plan 5×, 20× and 40× objectives |
|
|
Digital Cameras |
|
|
Magnetic base |
|
Model |
STM-6020 |
STM-6020M |
|
Microscope Body |
1 set |
1 set |
|
Plan eyepiece 10×/18mm |
1 unit |
1 unit |
|
LWD Plan Metallurgical Objective 10× |
1 unit |
1 unit |
|
LWD Plan Metallurgical Objective 50× |
1 unit |
1 unit |
|
LED Illumination |
1 set |
1 set |
|
Power source battery charger |
1 unit |
1 unit |
|
Magnetic base |
|
1 unit |
STM-6020 can be widely used for identification of casting quality, inspection of raw material or metallurgical structures, research and analysis of processed material in factory and laboratory, also can be used in antique gem and surface oSTMervation.
|
