Performance
Reliability
Safety
Ergonomic Design
|
|
Model |
STF-258C |
|
Technical Data |
Cabinet Type |
Chest |
|
Capacity (L) |
258 |
|
|
Climate Class |
N |
|
|
Cooling Type |
Direct Cooling |
|
|
Cooling System |
Single Compressor Auto-cascade System |
|
|
Defrost Mode |
Manual |
|
|
Refrigerant |
CFC-Free |
|
|
Door |
Single Solid Door |
|
|
Noise (dB) |
50 |
|
|
Performance |
Temperature Range (°C) |
-40 ~ -86 |
|
Cooling Performance (°C) |
-86 |
|
|
Control |
Temperature Control |
Microprocessor |
|
Display |
LED |
|
|
Material |
Interior |
SUS304 |
|
Exterior |
Powder Coated Steel |
|
|
Shelf |
N/A |
|
|
Insulation |
PU Forming |
|
|
Electrical Data |
Voltage/Frequency |
220~240V 50/60Hz 110V 60Hz |
|
Power (W) |
500 |
|
|
Dimensions |
Net/Gross Weight (kg) |
220/240 |
|
Internal Dimension (W/D/H, mm) |
780x500x660 |
|
|
External Dimension(W/D/H, mm) |
1510x885x1095 |
|
|
Packing Dimension(W/D/H, mm) |
1570x945x1230 |
|
|
Container Load (20'/40'/40'H) |
7/15/30 |
|
|
Functions |
High/low Temperature Alarm |
Y |
|
Remote Alarm Contact |
Y |
|
|
Power Failure Alarm |
Y |
|
|
Sensor Error Alarm |
Y |
|
|
Accessories |
Door Lock |
Y |
|
Caster |
6 |
|
|
Shelf/Chamber |
N/A |
|
|
Inner Door |
1 |
|
|
Remote Alarm Contact |
Y |
|
|
Test Hole |
Y |
|
|
Data logger |
Optional |
|
|
CO2 Backup System |
Optional |
|
|
LN2 Backup System |
Optional |
|
|
Others |
Certificate |
CE, ISO9001 |
